ultrasonic sensors

Ultrasonic Sensors Documentation

Carlo Gavazzi’s UA Series ultrasonic sensors are designed for both distance measurement and object detection in tough environments. The range consists of both M18 and M30 housings. Discrete output types are available for presence and absence detection, and are ideally suited for detecting objects,such as transparent objects, that cannot be reliably detected by other sensors.

Analog outputs are available on our ultrasonic sensors for applications requiring a measurement of the target object, such as detecting the level of fluid in a tank. The analogue models have your choice of 0-10 VDC or 4-20 mA outputs. Most of our ultrasonic sensors incorporate push button programming, which allow the set-points and output scaling to be configured with the push of a button.

Product Range

UA12 Series

Sensors in 12mm cylindrical metal housing. Sensing distance up to 200 mm

UA18 Series

Sensors in 18mm cylindrical plastic housing. Sensing distance up to 2.2 meters

UA18 Series

Sensors in 18mm stainless steel housing. Sensing distance up to 1.5 meters

UA30 Series

Sensors in 30mm cylindrical housing. Sensing Distance up to 3.5 meters

UA30 Series

Sensors in 30mm stainless steel housing. Sensing Distance up to 3.5 meters

UA30 Series

Sensors in 30mm cylindrical housing. Sensing Distance up to 6 meters
