The powerful but slim CLD2EB1BU24 provides three sensitivity ranges plus a fine tune adjustment from 250 ohm to 500K ohm, enabling for control with a wide variety of liquids, such as salt water, sewage and chemicals. DIN rail mounting and universal 24-240VAC/DC supply voltage simplifies installation, and the 17.5mm housing width minimizes panel space requirements.

For more cost sensitive applications, the economically priced CLP2EB1Bxxx retains the reliability and many features of the CLD2EB1BU24, at a lower price. This model provides a single mid-range sensitivity adjustment from 5K ohm to 150K ohm, and supports many common applications. Mounted via an 11-pin DIN-rail mountable socket, four different models are available for operating voltages of 24VDC, 24VAC, 115VAC, or 230VAC.

The new Conductive Level Controllers offer a reliable and cost effective solution for level measurement in markets such as Agriculture and Water/Waste Water.

Technical specifications include:

CLD2EB1BU24 DIN Rail Mount Housing:
	Two-point charging/discharging
	250 ohm to 500K ohm sensitivity
	24 to 240VAC/DC power supply
	17.5mm wide DIN rail housing
	One 8A/250VAC SPDT relay output
CLP2EB1B Plug-in Housing:
	Two-point charging/discharging
	5K ohm to 150K ohm sensitivity
	24VDC, 24VAC, 115VAC, or 230VAC power supply
	35mm wide, 11-pin plug-in housing
	One 8A/250VAC SPDT relay output

In addition to the new CLD/CLP Series, the entire family of Conductive Level Controllers, including single-point control with timer, 4-point control, and cascadable controllers are available from CARLO GAVAZZI’s North American network of sales offices and distributors, and can be seen here.

For more information about the CLD/CLP Series, please click on any of the links below:
