November 2017 - Carlo Gavazzi is pleased to announce the launch of two new families of economically priced electromechanical plug-in relays and accessories. The RCI Series are offered with either an 8 or 11 pin circular plug while the RRM Series are offered with either an 8 or 14 blade plug.
The RCI is a general purpose industrial relay, available in either 2 or 3 change over contact arrangement and is rated up to 10 Amps per pole. The RRM is a more compact industrial relay that can be purchased with either 2 or 4 changeover contacts. The 2-contact version is rated for 10 Amps, while the 4-contact version is rated for 5 Amps. Both families of relays are equipped with a diagnostic LED, push or twist to test mechanical flag and an orange mechanical status indicator.
Control input options include common coil voltages from 5-110 VDC and 12-240 VAC. Both relays are complemented by DIN rail mountable sockets and metal hold down springs. All relays and sockets are UL recognized, CSA approved and CE marked. The RCI and RRM relays can be used in a variety of industrial applications to control resistive loads or small motors. Both are ideal for control panels where a stable, yet cost-effective control relay is required.
The features of the RCI Series Relays include:
- 8 or 11 pin style circular terminals
- 2 or 3 change over contacts
- DPDT or 3PDT 10 Amp max current ratings
- 1/3 HP motor rating
- 250V max switching voltage
- Standard AC and DC coil voltages
- Mechanical flag, mechanical and LED indication
- Optional DIN rail sockets / metal hold down springs
- UL recognized, CSA approved and CE marked
The features of the RRM Series Relays include:
- 8 or 14 blade style terminals
- 2 or 4 change over contacts
- DPDT 10 Amp or 4PDT 5 Amp max. current ratings
- Up to 1/3 HP motor rating
- 250V max switching voltage
- Standard AC and DC coil voltages
- Mechanical flag, mechanical and LED indication
- Optional DIN rail sockets / metal hold down springs
- Optional auxiliary modules
- UL recognized, CSA approved and CE marked
The RCI and RRM Series Plug-in Electromechanical Relays are available from Carlo Gavazzi’s North American network of sales offices, distributors, and online at www.GavazziOnline.com
For more information on the RCI and RRM Series, please click on any of the links below:
| RCI Data Sheet | RRM Data Sheet | |
| Press Release | ||
| Distributor Pricing Information, Powerpoint Presentation and Cross Reference to Discontinued Relays | ||
