January 2011 - Carlo Gavazzi is proud to launch the next generation of our CLD & P Series of conductive liquid level controllers. We have taken the advanced, multi-function capabilities of previous models, added some additional options, and introduced a simplified user interface! With the multi-function capabilities and new options, we are able to streamline our product offering, from 63 mostly single-function models down to 16.

Some of the key features include: Expanded sensitivity ranges, with most models able to detect liquids from 250 Ohms to 500 KOhms Dip switches on previous models replaced with rotary switches on front panel for easier setup Teach-in push buttons replaced with potentiometers, allowing customers to install and program the sensor without liquid in tank 3 Power supply types: 24 VAC/DC, 115 VAC, and 230 VAC LED indicators for Power and Output indication New Tank-Well function allows a single controller to control pumping operations of both an in-ground well and above-ground tank Master-slave function allows up to seven controllers to be connected together New single point controller features a built in timer (up to 30 seconds adjustable) for filling or emptying applications

The new CLD & P Series replaces older CLD & P versions which had teach-in buttons, as well as older S-System single function controllers. A cross reference guide is available (see link below).

The new CLD & P Series are available in DIN-rail mount as well as plug-in style housings. All models are UL, cURus and CSA approved and carry the CE and RoHS marks.

For more information about the CLD & P Series, click on any of the links below.
